Fruit Juice/ Fruit Concentrate Processing Machinery

Vegetable Washing and Peeling Machine

Vegetable Washing and Peeling Machine is equipped with soft and hard bristled rollers which helps to remove dirt and soil and peels the skin under water spray. This machine uses less water and enery with maximum output. Potato, Ginger, Onion, Sweet Potato, Carrot, Lotus Stem, beetroot etc. can be cleaned. This machine is suitable for pickle manufactures, large kitchens, bakery and vegetable processing units.

Model	Motor Capacity	Production Output
Grainex -WP-600	1HP/ 1 Phase	130-230 kg/hr
Grainex -WP-800	1HP/ 1 Phase	180-300 kg/hr
Grainex -WP-1000	2HP/ 3 Phase	360-500 kg/hr
Grainex -WP-1500	2HP/ 3 Phase	240-400 kg/hr

Multifunctional Vegetable Cutting Machine

Multi Functional Vegetable Cutting Machine is a highly versatile machine, capable of cutting root vegetables, long vegetables and leaves. Root Vegetable Side can cut vegetables into cubes, julian or slices by changing blades. Vegetable like Onion, Potato, Carrot, Ginger, Cabbage Capsicum, Pumkin can be processed in this section. The other side of the machine is capable of cutting long vegetables and leafy vegetable in various length and thickness. Variable Frequency Drive is provided for cutting blade as well as conveyor for adjusting the cutting length and thickness easily. Coriander leaves, celery, chilli, beans, bitter gourd and all types of long vegetable can be processed in this section.

Model	Motor Capacity	Production/ Hr
AM-VMF-300	2.2kW	300-500 Kg

Cutting Blade Options

Cubing: 20x20x15mm and 15x15x15mm
Julian: 3mm and 6mm
Slice: 3mm and 6mm

Vegetable Slicing and Cutting Machine

Vegetable cutting and slicing machine slices vegetable in required thickness and then conveyed to chopping section. By changing various blades, it can cut all types of vegetables and fruits in to slices, cubes, diamond, strips, and waves etc. We can also process leafy vegetables with this machine. This machine is specially designed for pickle manufacturing industry and vegetable/ fruit processing units.

Model	Power (HP)	Capacity
Grainex -VSC-2I	1HP	130-600 kg/hr
Grainex -VSC-3I	2HP	200-1000 kg/hr

Bowl Chopper

Bowl Chopper can process various vegetables to be chopped quickly and easily. Ginger, Green Chilli, Cabbage, Carrot, Onion, Potato cab be processing in this machine. This machine is suitable for hotels, catering units, bakery, and for bulk cooking needs

Alpha-BC-10	2HP	10 Litre
Grainex -VSC-20	3HP	20 litre

Semi Solid Dozer with U-Blender

Grainex Semi Solid Dozer with U blender is a specially designed machine for filling any type of semi solid material like pickle, Juices with Solid Particles, cake batter etc. U Type blender is provided to maintain the homogeneity of materials to be filled. Chunk size of up to 20mm can be filled in this machine. This machine is designed according to CIP concept for easy cleaning of internal parts.

Semi Solid Dozer wit U Blender
Material of construction	: SS304
Blender Capacity	: 60 Litre
Compressor Required	: 2 HP, 210 Litre
Filling Range	: 50 Gram to 1000 Gram
Working Pressure	: 6 Bar
Production Output	: 900 to 1200 Dozes

Automatic Paste/ Liquid Filling Line

Grainex Machineries offers wide range of paste/ liquid filling machines which are widely used for food products, ayurvedic medicines and cosmetic/chemical products for filling paste, liquid and semi solids. We can fill viscous as well as non-viscous materials in this machine. 4 Head/ 6 Head automatic lines and Two Head/ Single Head Semi Automatic machines can be provided as per customer requirements. Hopper with heater and stirrer can be provided according to the material. Capping and Labelling can also be integrated with automatic lines. List of Products that can be filled: Food: Sauce, Honey, Fruit Juice, Creams, Mayonnaise, Peanut Butter, Ghee, Cake Batter, Chocolate Syrup, Curry Paste, Dosa Batter, Pickle etc. Ayurveda: Lehyam, Kritham, Arishtam, Oil etc Chemical/ Cosmetic: Hand Wash, Shampoo, Gel, Cream, Paint, Lubircant Oil etc”

Model	Working Mode	No. of Heads	Air Supply	Filling Range (ml)	Out Put
Grainex PF-V1	Semi Automatic	Single Head	400 LPM/ 6 Bar	10-100, 50-500, 200-2000	30-250, 100-1000, 1000-800 Bottles/Hr
Grainex PF-V2	Semi Automatic	Double Head	600 LPM/ 6 Bar	600-1000, 5000	800-1500 Bottles/Hr
Grainex PF-V4	Fully Automatic	Four Head	1200 LPM/ 6 Bar	100-1000ml	1200-1800 Bottles/Hr
Grainex PF-V6	Fully Automatic	Six Head	1800 LPM/ 6 Bar		1800-2700 Bottles/Hr

Features

Fruit Mill

Fruit Mill is used to crush fruits and vegetables for getting better juice extraction when squeezed in the fruit press. This is also used for grinding chili, onion etc to form paste.

Model	Motor Capacity	Output
Grainex -FM-150	3.0 HP	200-300 Kg/Hr
Grainex -FM-300	5.0 HP	400-500 Kg/Hr

Juice Extractor

Juice Extractor is a compact machine ideal for Extracting juice. This machine is made of Stainless Steel and detachable filter is provided for easy cleaning. This machine is portable, thus suitable for outdoor works. 50% more output is achievable compared to manual process.

Model	Output/ Hr	Motor Power
AM–CME–200	200 kg	0.5 HP
AM–CME–300	300 kg	1.0 HP

Fruit Pulper

Fruit pulper is designed to meet extraction of pulp from fruits and other pulpy items. This machine can also be used for pepper husking and spices washing.

Model	Motor Capacity	Output
Grainex -FM-150	3.0 HP	200-300 Kg/Hr
Grainex -FM-300	5.0 HP	400-500 Kg/Hr

Cooking Kettle

Grainex Cooking Kettles are double jacketed with high quality insulation. This gives 40% energy saving compared to conventional cooking pots.Kettles are available with stirrer for cosistant preparation. All models have inbuit tilting system for material dischrge.

Model	Vessel Volume	Motor Power
AM-CK-100	100 Litre	1.5 HP
AM-CK-200	200 Litre	2.0 HP
AM-CK-300	300 Litre	3.0 HP
